Xhorse XDBASK for Toyota 8A AKL Smart Key Adapter for Smart Key All Key Lost Work with VVDI Key Tool Plus
New XM38 Toyota smart key add key for all key lost requires data collection and calculation, and now you can use the VVDI Key Tool Plus to connect to the Internet for data processing to generate keys. This function needs to collect data from the ECU on the vehicle, the original OBD 8A Adapter cannot perform this function, it needs to be equipped with this new Xhorse 8A smart adapter.
Highlights:
No Need PIN code
Support all keys lost and add key
For VVDI Key Tool Plus Only. Does not work with vvdi2.
Support List:
forToyota Transponder 4A
forCOROLLA 2019-
forLEVIN 2019-
forALLION 2021-
forToyota Transponder 8A with Page4 : A8/A9/AA
AVALON 2019- 0410
IZOA 2018- 0410
CROWN 2018- 2110
VELLFIRE 2017- 0120
RAV4 2019.7- 0410
HIGHLANDER 2017- 2110
WILDLANDER 2019- 0410
PRADO 2018- 3330
ALPHARD 2017- 0120
LAND CRUISER 2017- 0020/F43
CAMRY 2018- 0410
PRIUS 2018- 0410
C-HR 2018- 0410
forLexus Transponder 8A with Page4:A8/A9/AA
ES 2018- 0440
NX 2017- 2110/F43
GS 2018- 0440
UX 2018- 0440
IS 2017- 2020
LS 2017- 0440
LX 2017- 0010/F43
How to Connect Xhorse XD8ASKGL Toyota 8A AKL Adapter with VVDI Key Tool Plus?
Xhorse XDBASK Toyota 8A Smart Key Adapter is divided into two parts:
Transfer adapter and cables. The smart authentication unit 89990 on the new smart Toyota has two types of plugs, so the connector is divided into: TOY-C1 TOY-C2. Compared with the car's IMMO box (ID code box), the location of the intelligent authentication unit is easier to find and operate. No worry about the complicated operation and disassembly when adding keys.
1. Prepare Xhorse Toyota 8A Adapter, TOY-C1 & TOY-C2;
2. Connect XD8ASK adapter & TOY-C1 cable;
3. Plug one end of adapter into VVDI Key Tool Plus Tablet, the other end to OBD line;
4. Plug OBD line to the car;
5. Connect the other end of TOY-C1 cable to the co-pilot intelligent control unit plug.
How to Locate for Toyota Smart Box?
For Toyota smart box new type often features:
1. A black case (some old types have a grey/ brown case)
2. Three plugs at least
3. Part number begins with "89990"
Notes:
1. Cables on XDBASK Adapter could insert into other modules
2. Most smart boxes are behind glove box on passenger's side, some are under dashboard on driver's side
Key Tool Plus and Toyota 8A Smart key adapter program steps:
Choose IMMO Program>>Asia>>for Toyota>>Select by type>> Smart key system
Backup smart box EEPROM data
Add smart key
Package List:
1set x Xhorse XDBASK forToyota 8A Smart Key Adapter
